Especificaciones (EN) - Kramatorsk NKMZ 4000 (ID: 76209)
| Type | Hot forging press |
| Manufacturer | Kramatorsk NKMZ |
| Model | 4000 |
| Nominal force | 4000 ton |
| Slide stroke | 400 mm |
| Number of slide continuous strokes per minute | 50 |
| Shut height (distance between bed in top position and slide bolster plate, stroke down) | 1000 mm |
| Bed adjustment | 15 mm |
| Distance between uprights clear | 1660 |
| Slide dimensions | |
| left-to-right | 1420 mm |
| front-to-back | 1420 mm |
| Bed dimensions | |
| left-to-right | 1570 mm |
| front-to-back | 1620 mm |
| Upper knockout stroke | 60 mm |
| Down knockout stroke | 125 mm |
| Uprights openings dimensions | |
| width | 770 mm |
| height | 995 mm |
| Main motor power | 185 kW |
| Overall dimensions | |
| left-to-right | 6100 mm |
| front-to-back | 4710 mm |
| height | 8680 mm |
| Height above floor level | 6820 |
| Mass | 400 ton |
Oferta comercial (en venta) - Prensa de forja Kramatorsk NKMZ 4000 - 4000 ton (ID:76209). Todos los detalles de esta oferta (costo, condiciones de pago y entrega) se pueden obtener de nuestro gerente haciendo clic en el botón "Enviar solicitud" . También podemos ayudarlo a encontrar otros equipos..Enviar solicitud
